Garden Single Arm 10m Q235 Street Lamp Pole With Hot Dip Galvanization

Place of origin

China

Material

SteelQ235,Q345

Application

Garden, Square, Street, Stadium etc.

Shape of pole

Tapered Round,

Shafts are made of steel sheet that folded into required shape

and welded by automatic welding machine

Brackets/ Arm

As per customer’s requirement

Wall thickness

2.5mm to 20mm

Welding

Using automatic internal and external double welding makes

the welding beautiful in shape. And confirms with international welding standard. .

Base plate mounted

Base plate is square or round in shape with slotted holes for anchor

bolt and dimension as per customer’s requirement.

Ground mounted

The length buried underground as per customer’s requirement.

Galvanizing

Hot dip galvanization with Chinese standard GB/T 13912-2002 or

American standard ASTM A123, IS: 2626-1985.

Powder coating

Pure polyester powder painting, color is optional according to RAL

color standard.

Jointing

Jointing of pole with insert mode, face to face joint mode .Every lighting

pole has a unique code. All sections belonging to one pole have the

same code, so it’s easy to assembly.

Wind Resistance

Against wind pressure of 160Km/h

Earthquake Resistance

Against earthquake of 8 grade

Quality Control

We strictly follow the standard of ISO9001-2008. Quality is in the first

place at every stage of production to

ensure the product compliance to the specification/standards.

Careful inspections are carried out by highly trained inspection

engineers during every procedure from raw material stage to

finished product and delivery.

Certificates

ISO9001:2008 etc.
